HIGEBER S 501
②wh,bn/gn,ye/gy,pk/bu,rd
③gn,ye/bk,bn/bu,vt/ye,bu,gy,bk,wh/rd,bk
④bnrd,bnbu/gn,ye/bk,bn/og,rd/whye,whbk,bu,gy/
bngr,bnye,gnbl,gnrd
⑤whrd,whye,whbk,whbu/og,rd/vt,bu/bn,bk/ye,gn
⑥wh,bu,whgn,bngn/ye,vt/bn,gn/bk,rd/gy,pk
⑦wh,bn/gn,ye/gy,pk/bk,vt/gypk,rdbu/bl,rd
⑧wh,bu,whgn,bngn/yebk,bubk,gnbk,rdbk/ye,vt/pk,
gy/rd,bk/bn,gn
Electrical and technical specifications
|
Rated voltage :
|
Uo/U 350/500V
|
|
Test voltage :
|
2000V
|
|
Insulation resistance :
|
(+20°C):≧20MΩx km
|
|
Bending radius: :
|
stationary : 4 x cable diameterØ
flexible : 12 x cable diameterØ |
|
Temperature range :
|
stationary : -50°C - 80°C
flexible : -40°C - 70°C |
|
Radiation resistance :
|
≤80×10cJ/kg
|
|
Flame retardant :
|
IEC 60332-1
|
Order Number |
Number of cores × Nominal cross-sectional area mm² |
Cable diameter ~mm |
Copper weight ~kg/km |
Cable weight ~kg/km |
