Rated voltage:Uo/U 600/1000V
Test voltage:2500V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :10 x cable diameterØ
flexible:20 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 70°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
Special characteristics:
● low mutual capacitance
● low transfer impedance
● excellent electromagnetic
compatibility (EMC)
● Stranded bare Cu conductor, fine wire
● Strand structure to VDE 0295,class 5 / IEC 60228 class 5
● Core insulation: polyethylene (PE)
● Core colours: black, brown, blue and green-yellow protective conductor
● Cores twisted in layers,with optimal lay lengths
● Aluminium foil screening, 100%
● Tinned copper braided screening
● Outer sheath: special PVC,flame retardant
● Sheath colour: transparent
EMC motor power supply cable with overall foil and copper screening used for the connection of a frequency converter with a frequency converter controlled motor.
Employed in connection with machine tools, handling gear, machining and processing equipment, assembly and production lines, etc. when exposed to mean mechanical strain.
Stationary installation and occasional free movement without exposure to tensile load and without forced movement control.
Installation in dry, damp and wet environments.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 108001 | 4G1.5 | 10.6 | 94 | 230 |
| 108002 | 4G2.5 | 12.3 | 150 | 300 |
| 108003 | 4G4.0 | 14.6 | 235 | 485 |
| 108004 | 4G6.0 | 16.4 | 320 | 630 |
| 108005 | 4G10 | 20.1 | 533 | 860 |
| 108006 | 4G16 | 23.4 | 789 | 1290 |
| 108007 | 4G25 | 27 | 1236 | 1860 |
| 108008 | 4G35 | 32.7 | 1662 | 2610 |
| 108009 | 4G50 | 36.1 | 2345 | 2950 |
| 108010 | 4G70 | 42.3 | 3196 | 3950 |
| 108011 | 4G95 | 47.7 | 4316 | 5300 |
| 108012 | 4G120 | 51.9 | 5428 | 6600 |
| 108013 | 4G150 | 57.5 | 6743 | 7040 |
| 108014 | 4G185 | 61.1 | 7639 | 8380 |
| 108015 | 4G240 | 69.3 | 11059 | 12165 |
