Rated voltage:Uo/U 450/750V
Test voltage:2500V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:-5°C - 70°C
stationary:-40°C - 70°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 4027xx | 16 | 7.8 | 154.0 | 160 |
| 4028xx | 25 | 9.7 | 240.0 | 260 |
| 4029xx | 35 | 10.9 | 336.0 | 350 |
| 4030xx | 50 | 12.8 | 480.0 | 500 |
| 4031xx | 70 | 14.6 | 672.0 | 680 |
| 4032xx | 95 | 17.1 | 912.0 | 925 |
| 4033xx | 120 | 18.8 | 1152.0 | 1170 |
| 4034xx | 150 | 20.9 | 1440.0 | 1450 |
| 4035xx | 185 | 23.3 | 1776.0 | 1800 |
| 4036xx | 240 | 26.6 | 2304.0 | 2320 |
| 4037xx | 300 | 29.5 | 2880.0 | 2890 |
