Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:15 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 611001 | 2x0.50 | 2.1x4.2 | 9.6 | 16 |
| 611002 | 2x0.75 | 2.3x4.6 | 14.4 | 21 |
| 611003 | 2x1.0 | 2.5x5.0 | 19 | 27 |
| 611004 | 2x1.5 | 2.8x5.8 | 29 | 37 |
