Rated voltage:Uo/U 600/1000V
Test voltage:3000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :5 x cable diameterØ
flexible:10 x cable diameterØ
Temperature range:
flexible:-25°C - 80°C
stationary:-40°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
● Stranded tinned Cu conductor, fine wire
● Strand structure to VDE 0295 class 5 / IEC 60228
class 5
● Core insulation: EPR-based compound
type 3GI3, to VDE 0207 part 20
● Core identification:
NSSHÖU-O: black single cores
NSSHÖU-J: up to 5 cores:
colour coded to VDE 0293
7 cores and over: black with printed
consecutive number coding
● Green-yellow protective conductor
(3 cores and over)
● Cores twisted in layers, with optimal lay lengths
● Rubber intersheath
● Outer sheath: polychloroprene 5GM5
to VDE 0207 part 21, oil-resistant
● Sheath colour: yellow with type marking
Heavy-duty rubber-sheathed flexible cable for the connection of mobile equipment, motors and machines when exposed to extreme mechanical strain. Suitable for usein dry and damp environments and for outdoor
and stationary surface installation.Employed in underground mining, open pit mining, tunnelling, on construction sites, quarries as well as for industrial applications, conveyors, agricultural and commerciallocations and areas exposed to explosion hazards.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| NSSHOU-O | ||||
| 808001 | 1x 16 | 12.0 | 154.0 | 280 |
| 808002 | 1x 25 | 15.1 | 240.0 | 395 |
| 808003 | 1x 35 | 16.4 | 336.0 | 510 |
| 808004 | 1x 50 | 18.5 | 480.0 | 705 |
| 808005 | 1x 70 | 20.4 | 672.0 | 920 |
| 808006 | 1x 95 | 23.6 | 912.0 | 1230 |
| 808007 | 1x120 | 26.0 | 1152.0 | 1500 |
| 808008 | 1x150 | 28.0 | 1440.0 | 1780 |
| 808009 | 1x185 | 31.9 | 1776.0 | 2,270 |
| 808010 | 1x240 | 35.0 | 2304.0 | 2,950 |
| 808011 | 1x300 | 38.0 | 2880.0 | 3,500 |
| 808012 | 2x1.5 | 12.8 | 29.0 | 195 |
| NSSHOU-J | ||||
| 808013 | 3x1.5 | 13.4 | 43.0 | 187 |
| 808014 | 3x2.5 | 14.9 | 72.0 | 285 |
| 808015 | 3x4.0 | 16.9 | 115.0 | 340 |
| 808016 | 3x6.0 | 18.1 | 173.0 | 510 |
| 808017 | 3x10 | 21.0 | 288.0 | 695 |
| 808018 | 3x16 | 26.5 | 461.0 | 950 |
| 808019 | 3x50/25 | 45.5 | 1680.0 | 3210 |
| 808020 | 3x70/35 | 52.8 | 2352.0 | 4300 |
| 808021 | 3x95/50 | 59.2 | 3216.0 | 5695 |
| 808022 | 3x120/70 | 66.5 | 4128.0 | 7110 |
| 808023 | 4x1.5 | 14.4 | 58.0 | 255 |
| 808024 | 4x2.5 | 17.5 | 96.0 | 360 |
| 808025 | 4x4.0 | 20.1 | 154.0 | 500 |
| 808026 | 4x6.0 | 21.4 | 230.0 | 623 |
| 808027 | 4x10 | 26.1 | 384.0 | 965 |
| 808028 | 4x16 | 32.0 | 614.0 | 1,405 |
| 808029 | 4x25 | 37.0 | 960.0 | 2,050 |
| 808030 | 4x35 | 40.6 | 1344.0 | 2,610 |
| 808031 | 4x50 | 46.4 | 1920.0 | 3,650 |
| 808032 | 4x70 | 53.4 | 2688.0 | 4680 |
| 808033 | 4x95 | 60.0 | 3648.0 | 6205 |
| 808034 | 4x120 | 67.8 | 4608.0 | 7170 |
| 808035 | 5x1.5 | 15.4 | 72.0 | 265 |
| 808036 | 5x2.5 | 18.3 | 120.0 | 373 |
| 808037 | 5x4.0 | 21.1 | 192.0 | 551 |
| 808038 | 5x6.0 | 24.4 | 288.0 | 730 |
| 808039 | 5x10 | 28.0 | 480.0 | 1,105 |
| 808040 | 5x16 | 32.0 | 768.0 | 1,655 |
| 808041 | 5x25 | 40.0 | 1200.0 | 2,410 |
| 808042 | 7x1.5 | 19.4 | 101.0 | 455 |
| 808043 | 7x2.5 | 20.0 | 168.0 | 550 |
| 808044 | 10x1.5 | 20.8 | 144.0 | 553 |
| 808045 | 12x2.5 | 26.0 | 288.0 | 785 |
| 808046 | 18x2.5 | 30.9 | 432.0 | 1,230 |
