Rated voltage:Uo/U 300/500V
Test voltage:2000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :12.5 x cable diameterØ
flexible:4 x cable diameterØ
Temperature range:
flexible:-30°C - 80°C
stationary:-40°C - 90°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
工作电压：
H05BQ-F Uo/U 300/500 V
H07BQ-F Uo/U 450/750 V
测试电压：
H05BQ-F min. 2000 V
H07BQ-F min. 2500 V
特性：
● 高耐磨性
● 抗水解，溶液，酸碱化学腐蚀及各种润滑剂
● PUR外护套防紫外线
● 特别坚固，抗冲击，耐撕裂
备注：
这些协调型号H05BQ-F和H07BQ-F替代VDE型号
VDE中不包含7G1,5mm²和12G1,5mm²，根据
VDE要求，这两种规格的型号为(H)07BQ标注。
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 123001 | 2x0.75 | 5.7- 7.4 | 14.4 | 50 |
| 123002 | 3G0.75 | 6.2- 8.1 | 22 | 66 |
| 123003 | 4G0.75 | 6.8- 8.8 | 28.8 | 79 |
| 123004 | 5G0.75 | 7.6- 9.9 | 36 | 97 |
| 123005 | 2x1.0 | 6.1- 8.0 | 19.2 | 59 |
| 123006 | 3G1.0 | 6.5- 8.5 | 28.8 | 72 |
| 123007 | 4G1.0 | 7.1- 9.3 | 38.4 | 90 |
| 123008 | 5G1.0 | 8.0-10.3 | 48 | 113 |
| 123011 | 2x1.5 | 7.6- 9.8 | 28.8 | 90 |
| 123012 | 3G1.5 | 8.0-10.4 | 43.2 | 109 |
| 123013 | 4G1.5 | 9.0-11.6 | 57.6 | 140 |
| 123014 | 5G1.5 | 9.8-12.7 | 72 | 168 |
| 123015 | 7G1.5 | 12.1-13.8 | 100.8 | 250 |
| 123016 | 2X2.5 | 9.0-11.6 | 48 | 115 |
| 123017 | 3G2.5 | 9.6-12.4 | 72 | 163 |
| 123018 | 4G2.5 | 10.7-13.8 | 96 | 206 |
| 123019 | 5G2.5 | 11.9-15.3 | 120 | 259 |
| 123020 | 7G2.5 | 14.9-17.8 | 168 | 370 |
| 123021 | 4G4 | 12.7-16.2 | 153.6 | 326 |
| 123022 | 5G4 | 14.1-17.9 | 192 | 410 |
| 123023 | 4G6 | 14.2-18.1 | 230.4 | 495 |
| 123024 | 5G6 | 15.7-20.0 | 288 | 585 |
