Rated voltage:Uo/U 600/1000V
Test voltage:4000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :12 x cable diameterØ
flexible:15 x cable diameterØ
Temperature range:
flexible:-5°C - 50°C
stationary:-30°C - 70°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 141001 | 1x4 | 8,0 | 39,0 | 68,0 |
| 141002 | 1x6 | 9,0 | 58,0 | 90,0 |
| 141003 | 1x10 | 9,0 | 96,0 | 140,0 |
| 141004 | 1x16 | 10,0 | 154,0 | 190,0 |
| 141005 | 1x25 | 11,0 | 240,0 | 290,0 |
| 141006 | 1x35 | 12,0 | 336,0 | 390,0 |
| 141007 | 1x50 | 15,0 | 480,0 | 510,0 |
| 141008 | 1x70 | 17,0 | 672,0 | 710,0 |
| 141009 | 1x95 | 19,0 | 912,0 | 960,0 |
| 141010 | 1x120 | 21,0 | 1152,0 | 1200,0 |
| 141011 | 1x150 | 23,0 | 1440,0 | 1480,0 |
| 141012 | 1x185 | 25,0 | 1776,0 | 1910,0 |
| 141013 | 1x240 | 28,0 | 2304,0 | 2370,0 |
| 141014 | 1x300 | 30,0 | 2880,0 | 2970,0 |
| 141015 | 2x1,5 | 12,0 | 29,0 | 185,0 |
| 141016 | 2x2,5 | 12,2 | 48,0 | 220,0 |
| 141017 | 2x4 | 13,2 | 77,0 | 275,0 |
| 141018 | 2x6 | 14,1 | 115,0 | 335,0 |
| 141019 | 2x10 | 16,2 | 192,0 | 450,0 |
| 141020 | 2x16 | 17,8 | 307,0 | 620,0 |
| 141021 | 2x25 | 21,0 | 480,0 | 930,0 |
| 141022 | 3x1,5 | 13,0 | 43,0 | 220,0 |
| 141023 | 3x2,5 | 14,0 | 72,0 | 280,0 |
| 141024 | 3x4 | 15,0 | 115,0 | 350,0 |
| 141025 | 3x6 | 16,0 | 173,0 | 420,0 |
| 141026 | 3x10 | 18,0 | 288,0 | 600,0 |
| 141027 | 3x16 | 20,0 | 461,0 | 770,0 |
| 141028 | 3x25 | 21,8 | 720,0 | 1120,0 |
| 141029 | 3x35 | 24,9 | 1008,0 | 1550,0 |
| 141030 | 3x50 | 25,2 | 1440,0 | 1750,0 |
| 141031 | 3x70 | 29,2 | 2016,0 | 2450,0 |
| 141032 | 3x95 | 32,0 | 2736,0 | 3250,0 |
| 141033 | 3x120 | 34,9 | 3456,0 | 4000,0 |
| 141034 | 3x150 | 39,2 | 4320,0 | 5000,0 |
| 141035 | 3x185 | 44,1 | 5328,0 | 6150,0 |
| 141036 | 3x240 | 49,2 | 6912,0 | 8000,0 |
| 141037 | 4x1,5 | 13,0 | 58,0 | 235,0 |
| 141038 | 4x2,5 | 14,0 | 96,0 | 290,0 |
| 141039 | 4x4 | 15,0 | 154,0 | 370,0 |
| 141040 | 4x6 | 16,0 | 230,0 | 470,0 |
| 141041 | 4x10 | 18,0 | 384,0 | 670,0 |
| 141042 | 4x16 | 20,0 | 614,0 | 930,0 |
| 141043 | 4x25 | 25,0 | 960,0 | 1440,0 |
| 141044 | 4x35 | 27,0 | 1344,0 | 1890,0 |
| 141045 | 4x50 | 28,0 | 1920,0 | 2300,0 |
| 141046 | 4x70 | 32,0 | 2668,0 | 3200,0 |
| 141047 | 4x95 | 36,0 | 3648,0 | 4250,0 |
| 141048 | 4x120 | 40,2 | 4608,0 | 5350,0 |
| 141049 | 4x150 | 45,8 | 5760,0 | 6550,0 |
| 141050 | 4x185 | 49,5 | 7104,0 | 8100,0 |
