Rated voltage:Uo/U 300/500V
Test voltage:4000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:15 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
工作电压：225V
（非电源或高压直流链接用）
测试电压(50Hz)：
线芯/线芯500 V
导体直流电阻（+20°C）：最大38,4Ω/km
绝缘电阻：≥100MOhm x km
互电容：~120 nF/km
耦合电容：~100 pF/100m
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|
