Rated voltage:Uo/U 300/500V
Test voltage:4000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:15 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
● Bare Cu wire
● Core insulation: expanded PE, halogen-free
● Core colours: red and green
● Cores twisted in layers,with optimal lay lengths
● PVC intersheath
● Overall screening with composite aluminium foil,
metal layer on the outside, and tinned copper
braided screening
● Outer sheath: special PVC, flame retardant
● Sheath colour: RAL 4001 red lilac
Cables designed to this new specificationand featuring this special structure allowinstallation times to be reduced to a frac-tion of the original time when using a com-mercial stripping tool. The pre-adjusted knife distances and cut-ting depths ensure that stripping of theouter sheath and removal of the braidedscreen can be performed in a single oper-ation and with maximum dimensional ac-curacy. Stripping and installation errors can beavoided.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 242001 | 1x2x0.64 | 8 | 26.3 | 75 |
