Rated voltage:Uo/U 600/1000V
Test voltage:4000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:7.5 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-30°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
● Stranded bare Cu conductor, fine wire
● Strand structure to VDE 0295,class 5 / IEC 60228 class 5
● Core insulation: special PVC
● Black cores with printed consecutive white number coding
● Protective conductor
JZ = green-yellow protective
conductor in the outer layer
(3 cores and over)
OZ = without protective conductor
● Cores twisted in layers, with optimal lay lengths
● Outer sheath: special PVC,flame retardant and UV-resistant
● Sheath colour: RAL 9005 black
Used as energy or connecting cable or as measuring and control cable in machine tool manufacturing, plant engineering and on assembly and production lines. Suitable for stationary installation or flexible applications with unrestricted mobility without forced movement control and without exposure to tensile load. Installation in dry and damp environments. Stationary installation is necessary when used for outdoor applications; the specified temperature limits must be observed. Use in water or soil not allowed.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 106001 | 2x0.5 | 7 | 9.6 | 75 |
| 106002 | 3G0.5 | 7.4 | 14.4 | 85 |
| 106003 | 3x0.5 | 7.4 | 14.4 | 85 |
| 106004 | 4G0.5 | 8.2 | 19.2 | 100 |
| 106005 | 4x0.5 | 8.2 | 19.2 | 100 |
| 106006 | 5G0.5 | 8.6 | 24 | 115 |
| 106007 | 5x0.5 | 8.6 | 24 | 115 |
| 106008 | 6G0.5 | 9.6 | 28.8 | 125 |
| 106009 | 7G0.5 | 10.2 | 33.6 | 135 |
| 106010 | 7x0.5 | 10.2 | 33.6 | 135 |
| 106011 | 8G0.5 | 10.7 | 38.4 | 150 |
| 106012 | 8x0.5 | 10.7 | 38.4 | 150 |
| 106013 | 10G0.5 | 11.4 | 48 | 175 |
| 106014 | 12G0.5 | 12.2 | 58 | 195 |
| 106015 | 12x0.5 | 12.2 | 58 | 195 |
| 106016 | 14G0.5 | 13.1 | 67 | 225 |
| 106017 | 16G0.5 | 13.7 | 77 | 245 |
| 106018 | 18G0.5 | 14.2 | 86 | 275 |
| 106019 | 20G0.5 | 15.3 | 96 | 290 |
| 106020 | 21G0.5 | 15.9 | 101 | 300 |
| 106021 | 25G0.5 | 17.3 | 120 | 330 |
| 106022 | 30G0.5 | 17.9 | 144 | 345 |
| 106023 | 32G0.5 | 18.4 | 154 | 350 |
| 106024 | 34G0.5 | 19.4 | 163 | 500 |
| 106025 | 40G0.5 | 20.8 | 192 | 560 |
| 106026 | 42G0.5 | 21.6 | 202.2 | 590 |
| 106027 | 50G0.5 | 23.1 | 240 | 700 |
| 106028 | 52G0.5 | 23.6 | 252 | 730 |
| 106029 | 61G0.5 | 24.5 | 293 | 820 |
| 106030 | 65G0.5 | 26 | 312 | 860 |
| 106031 | 80G0.5 | 27 | 384 | 950 |
| 106032 | 100G0.5 | 31 | 480 | 1020 |
| 106033 | 2x0.75 | 7.5 | 14.4 | 95 |
| 106034 | 3G0.75 | 8 | 22 | 105 |
| 106035 | 3x0.75 | 8 | 22 | 105 |
| 106036 | 4G0.75 | 8.7 | 28.8 | 125 |
| 106037 | 4x0.75 | 8.7 | 28.8 | 125 |
| 106038 | 5G0.75 | 9.5 | 36 | 135 |
| 106039 | 5x0.75 | 9.5 | 36 | 135 |
| 106040 | 6G0.75 | 10.3 | 43.2 | 160 |
| 106041 | 6x0.75 | 10.3 | 43.2 | 160 |
| 106042 | 7G0.75 | 11.1 | 50 | 180 |
| 106043 | 7x0.75 | 11.1 | 50 | 180 |
| 106044 | 8G0.75 | 11.7 | 58 | 210 |
| 106045 | 8x0.75 | 11.7 | 58 | 210 |
| 106046 | 9G0.75 | 12.6 | 65 | 225 |
| 106047 | 10G0.75 | 12.8 | 72 | 235 |
| 106048 | 12G0.75 | 13 | 86 | 250 |
| 106049 | 12x0.75 | 13 | 86 | 250 |
| 106050 | 14G0.75 | 14 | 101 | 280 |
