Rated voltage:Uo/U 250/0V
Test voltage:1500V
stationary :3 x cable diameterØ
flexible:6 x cable diameterØ
Temperature range:
flexible:-30°C - 50°C
stationary:-40°C - 70°C
导体电阻：（回路）≤ 13.7 Ohm/km
绝缘电阻：≥ 100 MOhm x km
互电容：≤ 100 nF/km
特性阻抗：100 Ohm
电缆规格：
电缆厚度 4.0 +/- 0.2 mm
边缘厚度 4.0 +/- 0.2 mm
上宽 6.5 +/- 0.2 mm
下宽 10.0 +/- 0.2 mm
芯线间距 3.6 +/- 0.2 mm
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 276001 | 2x1.5 black | s.o. | 28.8 | 60 |
| 276002 | 2x1.5 yellow | s.o. | 28.8 | 60 |
