Rated voltage:Uo/U 300/500V
Test voltage:2000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:7.5 x cable diameterØ
Temperature range:
flexible:-40°C - 80°C
stationary:-50°C - 80°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
● Stranded bare Cu conductor, extra-fine wire
● Strand structure to VDE 0295,class 6 / IEC 60228 class 6
● PVC-insulated cores
● Black cores with printed consecutive white number coding
● Green-yellow protective conductor
(3 cores and over) in the outer layer
● Cores twisted in layers,with optimal lay lengths
● Fabric lapping
● Outer sheath: special PUR,cold-flexible,halogen-free, oil-resistant
● Sheath colour: RAL 7001 grey
This cable meets the most stringent requirements when used in connection with drag chains or as control cable for mobile machine components with ultra-high bending load. The shear-proof, low-adhesion PUR outer sheath and the TPE core insulation ensure a long cable service life.
The PUR sheath provides excellent resistance against mechanical impact along with high abrasion resistance and superior oil resistance.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|
