Rated voltage:Uo/U 250/0V
Test voltage:1500V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:7.5 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 70°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
● Bare copper, extra fine wire conductors,
to DIN VDE 0295 cl. 6 col. 4 and 5
● Special PVC core insulation TI2, to
DIN VDE0281 part 1
● Cores colour coded to DIN 47100, see
Technical Informations
● Cores stranded in layers with optimal
selected lay-length
● Core wrapping with textile tape
● Tinned copper braided screen, approx. 85%
coverage
● Special PVC outer sheath TM2, to
DIN VDE 0281 part 1
● Colour grey (RAL 7001)
The ideal cable for use in cable trays. This high flexible cable is ideal for all areas requiring a high and fast flexing cable including the machine industries, robotics and all areas of highly mobile machine parts. The long working life offers a secure performance as well as economy. For applications which go beyond standard solutions (for example for composting appliances or high shelf conveyors with extremely high processing speeds etc.) we recommend for our especially developed enquiry sheet for energy guiding systems.
Before installation in cable trays please read the instructions. Further technical details see selection table for drag chain c ables, see lead text.
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|
